HyEndFed Dualband 40/30 200 Watt

HyEndFed Dualband for 40 and 30 meter.
Max. Power : 200 Watt PEP, SSB.
Length : 16,20 meter.
Enclosure : Polycarbonate IP67, 100% UV resistant.
SO239 Connector : Silverplated.
All hardware Stainless steel.
No radials or tuner needed
Excellent radiation efficiency due resonant design and low loss parts.

With a vent plug.

EQUALIZING PRESSURE USING MEMBRANE VENTS IMPROVES ENCLOSURE SEAL PERFORMANCE
protect seals on sensitive electronics against water, dust, dirt and liquids with rapid pressure equalization.
block contaminants such as dirt, dust or salts in changing environmental conditions.
rapidly equalize pressure also helps virtually eliminate condensation and reduce housing design complexity.

The VSWR measurements of this antenna are made at a height of 10 meters horizontally.
